0.96 inch OLED White Display Module SPI/I2C 128x64 - 6 Pin can be interfaced with any microcontroller using SPI/IIC protocols. The characteristics of this display module are high brightness, self-emission, high contrast ratio, slim/thin outline, wide viewing angle, wide temperature range and low power consumption.
OLED (Organic Light-Emitting Diode) is a self light-emitting technology composed of a thin, multi-layered organic film placed between an anode and cathode. In contrast to LCD technology, OLED does not require a backlight. OLED possesses high application potential for virtually all types of displays and is regarded as the ultimate technology for the next generation of flat-panel displays.
Features:
Specifications:
|
Display Size |
0.96 Inch |
|
Pixel Colour |
White |
|
OLED Driver IC |
SSD1306 |
|
Resolution |
128 x 64 Pixels |
|
Visual Angle |
>160 Degree |
|
Active Display Area |
21.74 x 10. 86mm |
|
Driving Voltage |
3.3-5V |
|
Operating Temperature |
-40º~70º Celsius |
|
Interface Type |
I2C IIC |
|
Length (mm) |
27.5 |
|
Width (mm) |
27.5 |
|
Height (mm) |
11 |
|
Weight (gm) |
7 |
Pin Description:
Package Includes:
1 x 0.96" OLED Display Module - SPI/I2C - 128x64 - 6 Pin (White)
