CD4511BE BCD to 7-Segment Decoder Driver IC – DIP-16
memory Technical Parameters & Datasheet Summary
SKU: ANIL2646The CD4511BE BCD to 7-Segment Decoder Driver IC is a CMOS BCD to 7-segment latch/decoder/driver IC designed to drive LED displays directly. It converts 4-bit binary-coded decimal (BCD) input into seven outputs to drive a 7-segment display efficiently. The IC includes features like lamp test, blanking, and latch enable, making it versatile for display-based applications.
Packaged in a DIP-16 package, this IC is widely used in digital clocks, counters, electronic meters, calculators, and embedded display systems. Its low power consumption and ability to source current for LEDs make it a reliable choice for both hobby and industrial projects.
Features:
- BCD (Binary Coded Decimal) to 7-segment decoder/driver
- Direct drive capability for LED displays
- Integrated latch function for stable display output
- Includes lamp test and blanking inputs
- Wide operating voltage range: 3V to 15V
- Low power CMOS design for efficient operation
- Standard DIP-16 package for easy prototyping
- Ideal for digital clocks, counters, and display projects
Specifications:
- Model: CD4511BE
- Function: BCD to 7-segment latch/decoder/driver
- Inputs: 4-bit BCD
- Outputs: 7-segment LED (a–g)
- Supply Voltage (VDD): 3V – 15V
- Logic Type: CMOS
- Package Type: DIP-16
- Special Features: Latch enable, lamp test, blanking
- Applications: Digital clocks, calculators, counters, meters, embedded display systems
Package Includes:
- 1 x CD4511BE BCD to 7-Segment LED Decoder Driver IC (DIP-16)
