1.44 inch TFT LCD Color Screen Module SPI Interface 128X128 without Touch

1.44 inch TFT LCD Color Screen Module SPI Interface display uses 4-wire SPI to communicate and has its own pixel-addressable frame buffer, it can be used with every kind of microcontroller. Even a very small one with low memory and few pins available!

This 1.44 inch TFT Color LCD Screen Module SPI Interface has 128 x 128 resolution and 262 colors, it uses SPI interface to communicate with the controller such as Arduino, it is the best upgrading of the Nokia5110.. Unlike the low cost “Nokia 6110” and similar LCD displays, which are CSTN type and thus have poor color and slow refresh, this display is a true TFT! The TFT driver (ST7735) can display full 16-bit color using our library code.

The breakout has the TFT display soldered on (it uses a delicate flex-circuit connector) as well as an ultra-low-dropout 3.3V regulator and a 3/5V level shifter so you can use it with 3.3V or 5V power and logic.

Features :

• TFT color screen, the effect is far better than other small CSTN screen
• Fully compatible and alternative 5110 interface
• Onboard LDO, support 5V/3.3V input voltage
• 1.44 inch color screen, support 65K color display, display rich colors
• 128X128 resolution, clear display

Specifications:

• Screen Size : 1.44(inch)
• Type: TFT
• Driver IC: ST7735
• Resolution: 128*128 (Pixel)
• Module Interface: 4-wire SPI interface
• Active Area (AA area): 26.2×27.2(mm)
• Module PCB Size: 29.7×43.36(mm)
• Operating Temperature: -20℃~60℃
• Storage Temperature: -30℃~70℃
• VCC power voltage: 3.3V~5V
• Logic IO port voltage: 3.3V(TTL)
• Weight: 12 (g)

Package Includes:

• 1 x 1.44 inch TFT LCD Color Screen Module SPI Interface 128X128 without Touch
