Graphic LCD Display 128x64 (Green) - JHD Make

We are offering quality tested Graphic LCD Green 128*64 - JHD make that can display not only alphanumeric data but simple graphics also. Fabricated from advance technology, these LCD's are highly suitable for animations and neat menus. Moreover, our product can handle the 128*64 pixels and comes with a black frame. Customers can avail this range in desired specifications and configurations at most competitive prices.

The display is fully programmable and can display a combination of both graphics and text. It can operate in both parallel modes. In SPI mode only 3 data pins are required to drive this display.

This 12864B LCD is a big, bold, beautiful Green LCD with white back-lit pixels. It is also well known for its wide use in 3D Printers, an extension accessory of RAMPS. If you want to add some visual output to your Arduino projects, you’ll need a display. This LCD display is best suited the graphical upgrade to those popular 16×2 LCDs but allows full graphical control.

Features:

• Display construction : 128*64 DOTS

• Display mode : Yellow Green

• Display type : Positive Tranflective

• Viewing direction : 6 o'clock

• Operating temperature : Indoor

• Driving voltage : Single power

• Driving method : 1/64duty, 1/9 bias

• Type : COB (Chip On Board)

• Number of data line : 8-bit parallel

• Connector : Header Pin

Package Includes:

• 1 x 128x64 Graphic LCD Display with Green Backlight
