IRS2007STRPBF Gate Driver IC Infineon SOIC-8
memory Technical Parameters & Datasheet Summary
SKU: ANIL2561IRS2007STRPBF Gate Driver IC Infineon SOIC-8 is a high voltage, high-speed power MOSFET and IGBT driver with dependent high and low side referenced output channels. Proprietary HVIC and latch-immune CMOS technologies enable ruggedized monolithic construction. The logic input is compatible with standard CMOS or LSTTL output, down to 3.3V logic.
The output driver features a high pulse current buffer stage designed for minimum driver cross-conduction. The floating channel can be used to drive an N-channel power MOSFET or IGBT in the high-side configuration which operates up to 200V. Propagation delay is matched to simplify the HVIC use in high-frequency applications.
Typical application includes appliance motor drives, stepper motor, servo drives, micro-inverter drives, general-purpose three-phase inverters, light electric vehicles (e-bikes, e-scooters, e-toys), wireless charging, general battery-driven applications.
Features:
- Gate drive supplies up to 20V per channel, undervoltage lockout for VCC, VBS
- 3.3V, 5V, 15V input logic compatible, tolerant to negative transient voltage
- Designed for use with bootstrap power supplies, cross-conduction prevention logic
- Matched propagation delay for both channels, internal set deadtime, 2kV HBM ESD
- High-side output in phase with HIN input, low-side output out of phase with active low LIN input
- Output voltage range from 10 to 20V
- Output high short circuit pulsed current is 200mA min (VO=0V, VIN=VIH, PW ≤ 10µs)
- Output low short circuit pulsed current is 420mA min (VO =15V, VIN=VIH, PW ≤ 10µs)
- Turn-on propagation delay is 160ns typ, turn-off propagation delay is 150ns typ (TA=25°C)
- 8 lead SOIC package, ambient temperature range from -40 to 125°C
Specifications:
- Manufacturer: Infineon Technologies
- Mfr. Part: IRS2007STRPBF
- Package: SOIC-8
- Description: Half Bridge 290mA 30ns 10V~20V 600mA SOIC-8 Gate Drivers
- Datasheet : Infineon Technologies IRS2007STRPBF
- Standard Packaging: 2500 / reel & No MOQ (Minimum Order Quantity)
Package Includes
- 1 x IRS2007STRPBF Gate Driver IC Infineon
