XH-M403 XL4016 High Power 8A DC-DC Digital Voltage Regulator Buck Step Down Power Supply Module

The XH-M403 XL4016 High Power 8A is a high-performance digital DC-DC buck converter module built around the XL4016 voltage regulator chip, designed to efficiently step down voltage with a powerful 8A maximum output current and up to 200W of power. With PWM modulation, this module enables smooth and stable adjustment of output voltage from 1.3V to 32V DC (input 5V to 36V), making it ideal for powering various electronics.

This 8A step down module features built-in protections for over-current, over-temperature, and short circuits, ensuring reliable and safe operation. Its digital display provides real-time voltage monitoring for user convenience.

Features:

• High power output up to 8A continuous current (recommended long-term use ≤ 5A)
• Wide input voltage range: 5V to 36V DC
• Adjustable output voltage: 1.3V to 32V DC via precision potentiometer
• Digital display for real-time output voltage reading with 0.1V accuracy
• PWM modulation for efficient voltage regulation and up to 94% efficiency
• Durable aluminum alloy radiator for effective heat dissipation
• Protection features include over-current, over-temperature, and short-circuit prevention
• High-quality XL4016 chip and premium electronic components with military-grade dual-layer circuit board
• Compact size for easy integration into various projects

Specifications:

• Model: XH-M403
• Input Voltage: DC 5V – 36V
• Output Voltage: DC 1.3V – 32V (adjustable)
• Maximum Output Current: 8A (Long-term recommended ≤ 5A)
• Maximum Power: 200W
• Conversion Efficiency: Up to 94%
• Switching Frequency: 180KHz
• Display: Digital LED voltage display
• Size: 78mm x 63mm x 40mm
• Weight: Approx. 49g
• Protection: Over-current, over-temp, short-circuit

Applications:

• Power supply for electronic DIY and maintenance projects
• Regulated power source for LED strips, motors, cameras, and sensors
• Rectifier bridge and power management applications
• Industrial and hobbyist electronics requiring stable voltage conversion

Package Includes:

• 1 x XH-M403 XL4016 8A DC-DC Digital Voltage Regulator Buck Step Down Power Supply Module
