2200mAh 3S 30C/60C (11.1 V) Orange Lithium Polymer Battery Pack (LiPo)
memory Technical Parameters & Datasheet Summary
SKU: Anil5392200mAh 3S 30C/60C Orange Lithium polymer battery Pack (LiPo) batteries are known for performance, reliability and price. It s no surprise to us that Orange Lithium polymer packs are the go-to pack for those in the know. 2200mAh 3S 30C/60C (11.1 V) Orange Lithium Polymer Battery Pack (LiPo) deliver the full rated capacity at a price everyone can afford.
Orange 2200mAh 3S 30C/60C Lithium polymer battery Pack (LiPo) batteries are equipped with heavy duty discharge leads to minimize resistance and sustain high current loads. Orange batteries stand up to the punishing extremes of aerobatic flight and RC vehicles. Each pack is equipped with gold plated connectors and JST-XH style balance connectors. All Orange Lithium Polymer batteries packs are assembled using IR matched cells.
You won't find a better deal than this in Lithium Polymer batteries anywhere!
Note: The battery dimensions and weight may have 2% error.
Features :
- Product Type: Lithium Polymer Battery Pack
- Weight : 175.0 g
- Dimensions : 23 x 34 x 106 (mm )
- The Orange LiPo battery has matched resistance.
- Good Temperature Control.
- Minimum weight in Class
Specifications:
| Model No. | ORANGE 2200/3S-30C |
| Capacity (mAh) | 2200 |
| Weight (gm) | 175 |
| Output Voltage | 11.1 V |
| Charge Rate | 1-3 C (Recommended) |
| Discharge Plug | XT-60 |
| Balance Plug | JST-XH |
| Length (mm) | 106 |
| Width (mm) | 34 |
| Height (mm) | 23 |
| Max. Burst Discharge | 60C(132.0A) |
| Max. Charge Rate | 5 C |
| Max. Continuous Discharge | 30C(66.0A) |
Package Includes :
- 1 x Orange 2200mAh 3S 30C/60C Lithium polymer battery Pack (LiPo)
Safety Precautions :
- Avoid over-charging or over-discharging the batteries.
- Do not put it beside the high-temperature condition.
- Don't throw it into the fire or Water
