1.3 Inch OLED Blue Display Module 128x64 SPI Interface - 7 Pin

The most attractive thing about using 1.3 Inch OLED Blue Display Module 128x64 SPI Interface - 7 Pin is that they do not need a back-light like conventional LCD/LED screens. The organic material itself has a property known as Electroluminescence (EL), which causes the material to “glow” when stimulated by a current or an electric field. Best energy saving displays ever!!!

This 1.3 Inch 128×64 OLED Display Screen Module offers 128×64 pixel resolution. They are featuring much less thickness than LCD displays with good brightness and also produce better and true colors.This OLED Display Module is very compact and will add a great ever user interface experience to your Arduino project. The connection of this display with Arduino is made through SPI interface.

The 1.3 Inch 128×64 OLED Display Screen Module produces blue text on black background with very good contrast when supplied with DC 2.8V supply. The OLED Display Modules also offers a very wide viewing angle of about greater than 160 degree.

Features :

• No need of the backlight
• The display is self-illuminating
• Power requirement is low
• They are offering the large viewing angle
• Full Compatible with Arduino
• The ultra-low power consumption of around 0.08w at full screen lit.

Specifications:

Pin Description:

• GND: GND.
• VDD: 3.3V (VCC).
• MOSI: D11 (don't change).
• SCK: D13 (don't change).
• D/C: D8 (can be any digital pin).
• RST: D9 (can be any digital pin).
• CS: D10 (can be any digital pin).

Package Includes :

1 x 1.3 Inch 128×64 OLED Display Screen Module with SPI Serial Interface
